Metrology Services

  • Part Layouts: Part print geometrical and Linear. With fixture, free-state or using PJF large in-house fixture sets.

  • 3rd Party Gage Certifications: Initial or annual verification.

  • Capability Study: Manual using variable data or pass/fail. Automated using CMM machine.

  • Gage R/Gage RR: Manual using variable data or pass/fail. Automated using CMM machine.

  • Mold Validation: CMM measurement or 3D Scanning.

  • 3d Scanning: Onsite or In-house. Color map, dimensional reports. Point clouds, STL files outputs. Using Metrologic X4 or Polyworks.

  • DOE (Design of Experiment)

  • Reverse Engineering: Scan to 3D model / surface creation available.

  • Offline Programming: PC-DMIS or Metrologic Silma X4 Software.

  • On-site Services: Programming or production running of parts in PC-DMIS or Metrologic Software.

Our Machine List



PJF Main (MI)

PJF North

Metrology (MI)

PJF South (SC)

PJF South

Metrology (SC)

  • (1) Zeiss DB 1200

  • (1) Mitutoyo Bright 1220

  • (2) Mitutoyo CHN 1612's

  • (2) Mitutoyo Bright 1220's

  • (1) Brown and Sharpe Global

  • (1) Mitutoyo Crysta

  • (1) Wenzel 12.20.10

  • *NEW* Hexagon Optiv Classic 321

  • *Coming Soon* Hexagon Absolute Arm: 7 Axis - 3.5Meter

  • (1) Mitutoyo CHN 1612

  • (2) Mitutoyo CHN 1612's

  • (1) Mitutoyo Bright 1230

  • (1) Brown and Sharpe Mistral

  • (1) Mitutoyo Crysta Apex

  • (1) Sheffield 12.20.10

  • (1) *NEW* Faro Quantum  7 axis - 3.5Meter



Software

  • Inspection software includes: Metrologic X4, Polyworks, Silma X4 and PC DMIS.

  • PJF Metrology South offers onsite support for both Metrologic, Polyworks and PC-DMIS, programming and/or operating.

  • PJF Metrology North offers onsite support for both Metrologic and PC-DMIS, programming and/or operating only.

  • PJF Metrology North is also beginning to offer offline programming services for both software’s as well.

  • PJF Metrology North runs two shifts with a total company count of 18

  • PJF Metrology South runs two shifts with a total company count of 5
